Automatic Hot Melt Glue Cover Paper Gluing Machine With High
Accuracy
LS-650A can be use in fo ders, file boxes, clothing boxes, shoe
boxes, hardcover cover and other products. this machine has hifh
effficiency, adaptability, hot melt adhesive, glue, latex can be
used. Variable speed, no wear, no deformation, feeding, high
precision.
This machine is mainly used for gluing boxes of various boxes.
Adopt PLC system, easy to operate. The working principle of
automatic folder gluer. The working principle of the automatic
folder-gluer is that after the power is turned on, the entire
conveyor belt starts to move, and the die-cut semi-finished cartons
are placed on the feeding position of the folder-gluer. Move
automatically. The set feeder feeds to the middle belt, and the
conveyor belt conveys the cartons to the rear folder-gluer for
pressure packaging.
Applicable products: documents boxes, clothing boxes, shoe boxes,
hardcover boxes and other products. This machine has high
efficiency and strong adaptability and can be used with hot melt
adhesives, adhesives and latex. Continuously variable speed, no
wear or deformation, and high feeding accuracy.
Adopts an indirect heating/temperature control method, so it can be
used even in places with poor working environments. System models
can be assembled into assembly lines in various formats depending
on product needs.
| Paper width | W80-600mm |
| Paper thickness | 80-250g |
| Glue speed | 7-40pcs/min |
| Voltage supply | 380v |
| Motor power | 7.45KW |
| Machine dimension | L7600*W1650*H1100mm |
| Machine weight | 1096kg |
LS-650A introduce
Use production:
Fo ders, file boxes, clothing box, shoes box, hardcover cover and
other products. This machine has hogh efficiency, adaptability, hot
melt adhesive, glue, latex can be use. Variable speed, no wear, no
deformation, feeding, high precision.
This machine has an indirect heating and temperature control
system, which can be applied to the place where theworking
enviroment is low. The system models can be assembled into various
forms of assembly line according to the needs of the product.
Feeder Paper Feed: This machine uses a paper feed servo to feed the
tissue paper into the rollers and adhere the adhesive.
Adhesive types: Automatic adhesive applicators can handle different
types of adhesives, including hot melt adhesives, water-based
adhesives, solvent-based adhesives, and UV-curable adhesives. The
specific type of adhesive that a machine can process depends on its
design and functionality.
Control System: These machines are equipped with advanced control
systems that enable accurate and consistent adhesive application.
The control system can include programmable settings for adhesive
volume, speed, temperature (for hot melt adhesives), and pattern
customization.
Machine feature:
1. Feeder paste machine mainly adopts vacuum suction and blowing at
the front end of the paper to suck and transport the paper, and the
conveying is stable and accurate;
2. The main machine is frequency-controlled and speed-regulated,
equipped with automatic heating and constant temperature system
with timing start;
3. The conveyor belt is equipped with a strong suction device to
avoid bending, deformation and displacement of the paper after
being glued;
4. Compatible with hot melt adhesive and cold adhesive, the glue is
applied evenly without wrinkling, and there is less waste in
recycling, which can effectively improve production efficiency and
save costs.
