LS-900C introduction
The automatic dual-channel high-speed and high-precision rigid box
visual positioning machine is an automated equipment specially used
to position rigid boxes. It has the characteristics of
dual-channel, high speed and high precision. The following is a
detailed introduction to the device:
| Machine model | LS-900C |
| Paper size(max) | L650*W400mm |
| paper size (min) | L130*W120mm |
| Cardboard size (max) | / |
| Cardboard size (min) | / |
| Box Size (Lenght) | L80-400mm |
| Box Size (Width) | W60-300mm |
| Box Size (Height) | H15-100mm |
| Working speed | 12-25 (pair)/min/single station 12-38/min |
| Robot accuracy | ±0.1mm |
| Paper thickness | 100-350g/m² |
| Paper staking height | 540mm/100kg |
| Cardboard thickness | 0.8-3mm |
| Edge folding size | / |
| Tuin in depth | / |
| Motor power | 9KW/380V 3phase |
| Heating power | 8KW |
| Air presure | 30L/min |
| Machine dimension | L6600*W3860*H2200mm |
| Weight of Machine | 2300kg |
Dual-channel design: The automatic dual-channel high-speed and
high-precision rigid box visual positioning machine has two
independent channels, which can process the box body and box lid of
the rigid box at the same time. This design can significantly
improve production efficiency, allowing the equipment to handle
multiple boxes at the same time and reducing production line
downtime. Can handle 25 pairs of boxes per minute, that is, fifty
boxes per minute
High-speed positioning: This equipment uses high-speed image
processing and algorithms to complete the positioning of the rigid
box in a very short time. High-speed positioning can increase
production
High-precision positioning: The automatic dual-channel high-speed
and high-precision rigid box visual positioning machine has
high-precision positioning capabilities and can accurately detect
and locate the position and attitude of the rigid box. This
high-precision positioning helps ensure accuracy and consistency
during assembly and production of rigid boxes.
Vision system: The device is equipped with an advanced vision
system, including a high-resolution camera and professional image
processing software. The vision system is able to capture images of
the rigid box and achieve accurate positioning through image
processing and analysis.
Automated transfer system: Automatic dual-channel high-speed and
high-precision rigid box vision positioning machines are usually
also equipped with an automated transfer system for transferring
rigid boxes from one workstation to another. The transfer system
quickly and accurately positions the boxes into the correct
position for subsequent assembly and handling.
Adjustability and Adaptability: The device typically has the
ability to adjust and adapt to different sizes and shapes of rigid
boxes. It can adapt to boxes of different specifications by
adjusting algorithms and parameters to meet different production
needs.
User interface and control system: The automatic dual-channel
high-speed and high-precision rigid box vision positioning machine
is equipped with an easy-to-operate user interface through which
the operator can monitor the operating status of the equipment and
perform settings. The control system can accurately control the
operation of the equipment to achieve high-speed and high-precision
positioning and assembly.
The automatic dual-channel high-speed and high-precision rigid box
visual positioning machine is an efficient and accurate automation
equipment that can greatly improve the production efficiency and
quality of the rigid box production line. It is suitable for
production environments that require high-speed and high-precision
positioning, and can quickly and accurately complete box
positioning and assembly tasks.
