Rigid Box Book Cover Gluing Machine Positioning Machine 40pcs/min For Packaging

Box Packing Machine For Rigid Box Making, Book Cover Making And Paper Lining

Introduction:

Box Packing Machine For Rigid Box Making, Book Cover Making And Paper Lining. This machine is also called as gluing and spotter machine. It can finish paper gluing and pasting box on the glued paper automatically, which is widely used for rigid box making, book cover machine, paper lining and even album making.

LS-450plus is a multi-function visual positioning machine. It is able to positioning the rigid box and hardcover. also can do paper lining, one machine with many functions, and the working model is able to be changed by one button. The visual positioning system is able to be upgraded. Moreover, this machine also can be upgraded to an automatic line in the future if needed.

Equipped with dual cameras, the cameras are located on both sides of the central position of the conveyor belt. The camera position has been calibrated before leaving the factory. If there is any deviation, you can adjust the camera position by adjusting the upper camera "mounting plate". After the camera takes a picture, the system recognizes the color difference of the photo for positioning. If the surface paper and the surface paper conveyor belt are similar in color, it can be solved by changing the belt color.

Main features:

1. High speed, Max speed is 40 pcs/min.

2. Easy operation, the min setting time of change model is 7 minutes.

3. Dual feeding system, one button change box feeding to hardcover feeding system.

4. Anti-leaking gluing system.

5. Panasonic Servo motor feeding system.

Advantages:

Flexible

Can connect with four sides wrapping machine to make the hardcover

Can work with box wrapping machine to make rigid box

Can make special box, such as slant side box (videos are available)

High speed

With 2 sets LS-F7 shoe box folding machines, the speed of machine can make around 14000 pcs per day

Save setting time

Only need 7 minutes when change product mode

One bottom to change case to box

No stop working when change different size, because one F6 for presetting and another one can keep working

Optional function:

Glue Viscosity Device: Automatic detecting the hot melt glue thickness.
Air Operated Double Diaphragm Pump: Applied in white glue pumping.
Bottom sucker hardcover feeding device: Special design for feeding hardcover, to avoid scraping hardcover.

Specifications of LS-450plus:

Type	LS-450plus
Paper size (Max)	L800*W600mm
Paper size (Min)	L135*W100mm
Max box size	L600W400H120mm
Min box size	L80W65H15mm
Book cover (Max)	L750*W450mm
Book cover (Min)	L150*W100mm
Paper thickness	100-350g/㎡
Paper stacking height	280mm
Motor power / voltage	7.5kw/380v, 3 phase
Heating power	8kw/380v, 3 phase
Air supply	10L/min 0.6Mpa
Working speed	15-45 sheets/min
Machine dimension	L5980W3180H2100mm
Weight of machine	2100kg
