L5985mm Paper Gluing Machine W3183mm Rigid Box Positioning Machine

Ask Lasest Price
Brand Name :	Longxingsheng
Model Number :	LS-450plus
Certification :	CE, ISO9001
Price :
Payment Terms :	T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :	17 sets/month
Delivery Time :	7-15 work days

Add to Cart

Product Details
Company Profile

L5985mm Paper Gluing Machine W3183mm Rigid Box Positioning Machine

Autoamtic Paper Gluing Machine And Box Positioning Machine For Rigid Box Making

Introduction:
Mobile Phone & Cell Phone Box Gluing Machine & Pasting Machine. This machine is also called as gluing and spotter machine. It can finish paper gluing and pasting box on the glued paper automatically, which is widely used for rigid box making, book cover machine, paper lining and even album making.

Test page
Long press the blank space in the upper right corner of the Start page to bring up this page.

Paper alarm:Click the box to enter the number of paper alarms. When the machine is in normal operation, the paper sensor alarm sensor can not detect the number of paper reaches the set value, the machine will automatically alarm.
Feeder inching speed:can set the speed of feeder inching speed.
Feeder reset:Jog feeder back to the original position. Click the arrow to control the extension/retraction of the feeder.
Feeder current position:Show the current position of feeder.

Main features:

1. High speed, Max speed is 40 pcs/min.

2. Easy operation, the min setting time of change model is 7 minutes.

3. Double Germany Basler cameras (ten million pixels).

4. Dual feeding system, one button change box feeding to hardcover feeding system.

5. Anti-leaking gluing system.
6. Storage function for the positioning part, easy to adjustment

Advantages:

Flexible

Can connect with four sides wrapping machine to make the hardcover

Can work with box wrapping machine to make rigid box

Can make special box, such as slant side box (videos are available)

Can do paper lining

High speed

With 2 sets F6 box wrapping machines, the speed of machine can make around 12800 pcs per day

Save setting time

Only need 7 minutes when change product mode

One bottom to change case to box

No stop working when change different size, because one F6 for presetting and another one can keep working

Optional function:

Glue Viscosity Device : Automatic detecting the hot melt glue thickness.
Air Operated Double Diaphragm Pump: Applied in white glue pumping.
Bottom sucker hardcover feeding device: Special design for feeding hardcover, to avoid scraping hardcover.

Specifications of LS-450plus:

Type	LS-450plus
Paper size (Max)	L800*W600mm
Paper size (Min)	L135*W100mm
Max box size	L600W400H120mm
Min box size	L80W65H15mm
Book cover (Max)	L750*W450mm
Book cover (Min)	L150*W100mm
Paper thickness	100-350g/㎡
Paper stacking height	280mm
Motor power / voltage	7.5kw/380v, 3 phase
Heating power	8kw/380v, 3 phase
Air supply	10L/min 0.6Mpa
Working speed	15-45 sheets/min
Machine dimension	L5980W3180H2100mm
Weight of machine	2100kg

Company profile:

Dongguan Longxingjian Intelligent Equipment Co.,Ltd

We are one of the leading & professional manufacturer of Grooving machines and Fully Automatic/Semi-automatic Rigid Box Making Machine in Dongguan, China Since 2006. As a packaging technology company, we own 120 workers, more than 10 years experience, ISO & CE certificated, less than two hours reach Guangzhou or Shenzhen port, this is how we keep good quality and competitive prices for global valued customers.

We hold "professional, focus, customer first" as our operating principle, insist on surviving from good quality, improving efficiency from prescise management, developing from creativity. We are committed to spare no effort to become the national brand and contribute our strength in Printing&Packaging industry.

Our service:

L5985mm Paper Gluing Machine W3183mm Rigid Box Positioning Machine

Pre-sale service:

* Inquiry and consulting support.
* Sample testing support.
* Factory visit.

* Details discussion.

After-sale service:

* Machine installation and training in customer factory.
* Engineers available to service machinery overseas.
* On-line technology support.
* Free machine parts replacement during warranty.
* Whole life of machine service.
